5300QDC
At a glance…
- Sewing
- Optic Magnifiers
- 7mm stitch width
- Extra wide table
- Weight 6.9Kg
The 5300QDC is the perfect machine for dressmaking, quilting and crafting. This machine gives you time-saving features with an automatic thread cutter which trims the top and a bobbin thread simultaneously, the knee lifter allows you to lift the presser foot using your leg, giving you the freedom to use 2 hands on your creative stitching. The 300 Built-in Stitches allows you to create using a variety of stitching techniques – Heirloom, Applique, Top Stitching, hand-look quilting, lettering, decorative stitching, stitch building, thread painting and more. For bigger projects included is a large extension table, when fitted to the machine it substantially increases your workarea. Wanting perfect stitch alignment or you just need to simply have a better view of your stitching, this model has 3 different strengths of optic magnifiers, when attached to the machine you can adjust the viewing angle or when not required, simply swing it to the side or remove it. Program stitch combinations of up to 50 patterns with the option for mirror editing. The versatile stitch chart clips right onto the machine for easy viewing. Flip to read both sides of the chart, and fold to the back of the machine for simple storage.
Own this machine already? Register your warranty
Compare Find a Stockist
PRODUCT INFORMATION
Additional information
Work Space | 170mm (6.7") x 110mm (4.3") |
---|---|
Sewing Speed | Up to 820 stitches per minute. |
Machine Screen | LCD with backlight |
Built-in Stitches | 300 |
Stitch Width | 7mm |
Buttonholes | 12 |
Needle Positions | 15 |
Foot Pressure | Yes, 6 levels |
Needle Threader | Yes, superior type |
Lighting | White LED light |
Standard Sewing Feet | 11 |
Extra Wide Table | Yes |
Machine Size | W406 x H302 x D175mm |
Weight | 6.9Kg |
Free Arm Length | 90mm from needle |
Quick Reference Stitch Chart | Yes |
Stitch Length | Up to 5mm. |
Speed Control Slide | Yes |
Stitch Elongation | No |
Mirror Image Stitches | Yes |
Startover | Press the Memory Key to start the stitch at the beginning again. |
Bobbin Winder | Yes |
Fonts in Normal Sew | 1 font (Block) with numbers |
Drop Feed | Yes |
Superior Plus Feed System | 7 piece feed dog; no more fabric slipping, puckering and shifting |
Needle Plate | Easy Set Bobbin feature and has patented needle plate markings for precision sewing with needle drop position, angle marks and sewing guides in front of the sewing foot. In front of the bobbin cover are seam guide markings from left to right: 1/4 inch, 3/8 inch & 5/8 inch. |
Thread Cutter | Automatic thread cutter; cuts top & bobbin thread at the same time, pulling top thread to underside. |
Stop/Start Button | Ability to sew without a foot control attached. Holding the Start/Stop button when starting to sew, makes the machine sew slowly. When finishing press & hold the Start/Stop button and the machine will sew slowly then stop when you release the button. |
Needle Up/Down Function | Yes, this function as a memory setting. Default setting is to finish in the down position. |
Auto Lock-off Stitch button | Locks off your stitching at the push of button. |
Reverse Button | Yes |
Magnifier | Yes, the set of 3 AcuMagnifiers are supplied with this machine (20/40/60) Magnifications being 1.2x / 1.4x / 1.6x |
Adjustable Knee Lifter | Has a standard knee lift, not adjustable. |
Upper Thread Sensor | No |
Bobbin Thread Sensor | No |
Storage | Accessory box |
Carry Handle | 90°rotary short type(136mm) Neatly folds into the top of the machine. |
Foot Control | Yes |
Internal Frame | Rigid die-cast aluminium frame for stable sewing at high speeds |
STANDARD ACCESSORIES
STANDARD ACCESSORIES
· Zigzag Foot A |
· Overedge Foot C with brush |
· Zipper Foot E |
· Satin Stitch Foot F |
· Open-to Satin Stitch Foot F2 * |
· Blind Hemming Foot G |
· Overcast Foot M |
· 1/4˝ Seam Foot O * |
· Automatic Buttonhole Foot R |
· Darning Foot (open-toe) * |
· Even Feed Foot (open-toe) with Quilt Guide * |
· Cloth Guide * |
· Optic Magnifier 20 with Magnifier Holder |
· Optic Magnifier 40 |
· Optic Magnifier 60 |
· Quilt Attachment Set * (above parts with * located in set) |
· Janome Plastic Bobbins x 4 |
· Needle Set (Janome needles) |
· Additional Spool Pin |
· Screwdriver (lge) |
· Lint Brush |
· Seam Ripper (buttonhole opener) |
· Spool Holder (large) x 2 |
· Spool Holder (small) x 2 |
· Foot Control |
· Wide Extension Table (white) |
· Knee Lift (standard, not adjustable) |
· Power Cable |
· Instruction Book |
· Instructional Video DVD |
· Quick Reference Stitch Chart + chart holder |
· Hard Machine Cover |
OPTIONAL ACCESSORIES
OPTIONAL ACCESSORIES
FEET | ATTACHMENTS | |
Part Number | Description |
820815002 | Applique Foot F |
200321006 | Beading Foot (set of 2) up to 4mm beads |
202504001 | Bi-Level Foot 7mm/5mm top-loading |
200313005 | Binder Foot |
820817015 | Adjustable Blind Hem Foot |
200434003 | Border Guide Foot |
200136002 | Button Sewing Foot T |
202135007 | Circular Sewing Attachment ESB |
200345006 | Cording Foot (3 thread slots) |
200349000 | Darning Foot (closed-toe) |
202002004 | Convertible Free Motion Foot Set |
200341002 | Ditch Quilting Foot |
200449001 | Clear View Quilting Foot & Guide Set |
200311003 | Even Feed Foot with guide |
200339007 | Even Feed Foot with guide (open-toe) |
214518005 | Ditch Quilting Guide & Adjustable Quilting Guide for even feed ft with guide |
214517004 | Convertible Even Feed Foot SET |
941660000 | Fringe Foot |
200315007 | Gathering Foot |
820809014 | Hemming Foot D (2mm) |
200326001 | Hemming Foot Set (4mm & 6mm) |
200317009 | Pin Tuck Foot Set (7 & 5 groove) |
202213000 | Pintucking Cord Guides ESB |
200314006 | Piping Foot |
202502009 | Piping Foot (narrow) 7mm/5mm top-loading |
200332000 | Ribbon/Sequin Foot |
200316008 | Roller Foot |
943100000 | Ruffler |
202218005 | Sliding Guide Foot |
200331009 | Straight Stitch Foot |
202311009 | Taping Guide Foot |
801426003 | Tricot Foot |
200329004 | Ultra Glide Foot |
200333001 | Concealed® Zipper Foot [Conceal is a registered trademark of YKK Corporation] |
200342003 | Adjustable Narrow Zipper Foot (L/C/R) |
820811008 | Invisible Zipper Foot (wide) |
BOBBIN CASE | NEEDLES | BOBBINS | |
Part Number | Description |
202006008 | Bobbin Holder for Free Motion Quilting |
990109000 | Needle Size 9 (15×1) Sharp |
990111000 | Needle Size 11 (15×1) Sharp |
990112000 | Needle Size 12 (15×1) Sharp |
990114000 | Needle Size 14 (15×1) Sharp |
990116000 | Needle Size 16 (15×1) Sharp |
990118000 | Needle Size 18 (15×1) Sharp |
990100000 | Needle Mixed (15×1) Sharp |
202122001 | Purple Tip Needles #14 BP |
200346007 | Blue Tip Needles #11 BP |
990416000 | Denim Needles #16 |
990500000 | Top Stitch Needles #11/14 |
990600000 | Leather Needles #11/14/16 |
5105080BL | Organ Universal Needle – size 12/80 [pack 5] |
5506000BL | Organ Microtex Needle – size 8/60 x 3 | size 9/70 x 2 [slim sharp point] [mixed pack 5] |
5116000BL | Organ Titanium Needle – size 11/75 x 2 | size 12/80 x 2 | size 14/90 x 1 [mixed pack 5] |
5117075BL | Organ Embroidery Anti Glue Needle – size 11/75 [pack 5] multi-directional stitching |
820828008 | Twin Needle (2mm) sharp |
5102048BL | Organ Twin Needle – size 12/80 width 4mm |
5102057BL | Organ Stretch Twin Needle – size 11/75 width 4mm |
202010027 | Plastic Bobbins x 10 BP |
202010038 | Plastic Bobbins x 5 BP |
